A-MX610HD
12/13/14th Gen. Intel® Core™ i9/i7/i5/i3 Processors, Thin Mini ITX Motherboard With Intel® H610E Chipset
- 12/13/14th Gen. Intel® Core™ i9/i7/i5/ i3/Pentium/Celeron Processor with Intel® H610E Chipset
- 2 x 262-Pin DDR5 4800 MHz SO-DIMM Socket Supports Up to 64GB (Non-ECC)
- HDMI, LVDS, Optional eDP
- 1 x PCIe x16 (Gen4)
- 1 x Intel® I219V, 1 x Intel® I225LM
- 4 x USB 3.2, 6 x USB 2.0
- 1 x M.2 M-Key 2242/2280, 1 x M.2 E-Key 2230
- 3 x COM
- DC in +12V~24V
Datasheet
Product Specification
| System Information | |
| Processor | LGA 1700 Socket Supports 12/13/14th Generation Intel® Core™ i9/i7/i5/i3/Pentium/Celeron Processors (Max. TDP at 65W) |
| Platform Controller Hub | Intel® H610E Chipset |
| System Memory | 2 x 262-Pin DDR5 4800MHz SO-DIMM Socket Supports Up to 64GB (Non-ECC) |
| I/O Chipset | nuvoton NCT6126D |
| Watchdog Timer | H/W Reset, 5~255 Seconds/5~255 Minutes |
| BIOS | AMI uEFI BIOS, 256Mbit SPI Flash ROM |
| H/W Status Monitor | CPU Temperature Monitoring Voltage Monitoring CPU Fan Speed Control |
| TPM | Onboard infineon SLB 9670VQ2.0 support TPM2.0 |
| Board | Thin Mini ITX |
| Expansion | |
| Expansion | 1 x PCIe x16 (Gen4) 1 x M.2 M-Key 2242/2280 NVMe (PCIe x4 + SATA III) 1 x M.2 E-Key 2230 CNVi (PCIe x1 + USB 2.0) |
| Display | |
| Graphic Chipset | Intel® Integrated UHD Graphic with Xe Architecture (CPU Dependent) |
| Spec. & Resolution | 1 x HDMI 1.4b 4K@30Hz 1 x Dual Mode DisplayPort 1.2a 4K@60Hz 18/24-bits Dual Channel LVDS |
| Multiple Display | Triple Display |
| LVDS | Dual Channel 18/24-bits LVDS (Chrontel CH7513A-BF eDP to LVDS) or 1 x eDP 1920 x 1080@60Hz (2 Lanes) |
| Audio | |
| Audio Codec | Realtek ALC897 HD Audio Decoding Controller |
| Audio Interface | Mic-in, Line-out |
| Audio Amplifier | 2 x 6W 8Ω Amplifier |
| Ethernet | |
| LAN Chipset | 1 x Intel® I219V Gigabit Ethernet 1 x Intel® I225LM 2.5 Gigabit Ethernet |
| Ethernet Interface | 10/100/1000 Base-Tx GbE compatible & 2.5 Gigabit Ethernet |
| LAN Port | 2 x RJ-45 |
| Software Support | |
| OS | Windows 11, Linux |
| Certification | |
| Certification Information | CE, FCC, RoHS Compliant |
| I/O | |
| USB | 2 x USB 3.2 2 x USB 2.0 2 x USB 3.2 Gen1 by pin header 2 x USB 2.0 by pin header |
| COM Port | 1 x RS-232 2 x RS-232/422/485 |
| SATA | 2 x SATA III 2 x SATA power |
| DIO | 1 x 8-bit GPIO |
| Mechanical & Environmental | |
| Operating Temp. | 0°C to 60°C (32°F ~ 140°F) |
| Storage Temp. | -20° C ~ 80° C (-4°F ~ 176°F) |
| Operating Humidity | 5% to 90% Non-condensing |
| Weight | 0.88lbs (0.4Kgs) |
| Power Requirement | DC in +12V~24V |
| Power Mode | AT/ATX (Default Setting: ATX) |
| Dimension (L x W) | 6.7" x 6.7" (170mm x 170mm) |
