I-RACK-5000B
5U ATX Rackmount Chassis, 2 x USB2.0, Black, ATX Power Switch, HDD shockproof
- RoHS compliant design
- Compatible with ATX and microATX form factor motherboards
- Two 3.5” and three 2.5” drive bays
- Four cooling fans (92 x 92 x 38mm)
- Lockable door prevents unauthorized access
Datasheet
Product Specification
RACK-5000B is a 5U, 7-slot rackmount chassis designed to support ATX and micro ATX motherboards, as well as ATX power supplies of up to 600W. It is fully compatible with NVIDIA RTX 4090 GPUs, ensuring accelerated deployment of intelligent AIoT technologies.
As edge computing demands greater multitasking and high-performance capabilities, RACK-5000B seamlessly integrates CPU and GPU functionality for efficient large-scale parallel processing.
This industrial-grade solution is tailored for various edge AI applications, including image processing, automated optical inspection (AOI), machine vision, network security, intelligent transportation and video surveillance.
| Form factor | |
| SBC Form Factor | ATX Motherboard |
| I/O Interface | |
| I/O Ports | 2 x USB |
| Expansion Slots | |
| Expansion Slots | 7 slots |
| System | |
| Cooling method / System Fan | 4 |
| Drive Bays | 2 x 3.5” HDD 3 x 2.5” HDD |
| Indicator&Buttons | |
| Buttons | Power switch, reset button |
| Indicators | Power, HDD |
| Physical Characteristics | |
| Construction | Heavy duty metal |
| Color | |
| Color | Black chassis with silver frame |
| Dimensions | |
| Dimensions | 562.5 x 431 x 200.2 mm |
| Environment | |
| Operating Temperature | 0°C ~ 60°C |
| Humidity | 10% ~ 90% |
| Operating Vibration | Half-sine wave shock 5G, 11ms, 100 shocks per axis (SSD) |
| Operating Shock | MIL-STD-810G 514.6C-1 (SSD) |
| Safety & EMC | CE/FCC compliant |
