E-2210L
21.5” (16:9) Non-touch Monitor. Resolution: 1920 x 1080
- Durable and versatile 22-inch monitor built for commercial-use
- Easy-to-clean, anti-glare edge-to-edge glass displays
- Multiple mounting options with integrated VESA including – tabletop stand, wall mount and pole mount
- With a port cover that can be locked into place, cables are less prone to becoming disconnected, minimizing disruptions to the device
Datasheet
Product Specification
The 2210L 22-inch Monitor delivers the superior quality Elo is known for in a non-touch display. Designed for durability, the Elo 22-inch monitor features anti-glare edge-to-edge glass with IK06 impact resistance, enhanced ESD performance and a ventless back and cable cover design to help reduce foreign contaminant ingress. From digital signage and kitchen display systems to dashboards, medical carts and production line monitors, the 2210L monitor provides a reliable, cost-effective display in a thin, compact form factor.
| Part Number(s) | E448150 |
| Enclosure Color | Black |
| Touch Technology & Capacity | Non-Touch |
| Diagonal Size | 21.5'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
| Active Area | 18.84" x 10.25" / 478.66 mm x 260.28 mm |
| Resolution | 1920 x 1080 |
| Other Supported Resolutions | 640x480 60Hz, 640x400 70Hz 720x400 70Hz 800x600 56, 60Hz 1024x768 60Hz 1280x720 50, 60Hz 1280x800 60Hz 1280x1024 60Hz 1366x768 60Hz, 60Hz RB 1440x900 60Hz, 60Hz RB 1680x1050 60Hz, 60Hz RB 1920x1080 50Hz, 60Hz |
| Viewing Angle | Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total |
| Number of Colors | 16.7 million |
| Brightness (typical) | LCD panel: 250 nits With AG screen: 220 nits |
| Response Time-total (typical) | 20 msec |
| Contrast Ratio | 3000:1 |
| Surface Treatment | Anti-glare |
| On Screen Display | The unit has on-screen display (OSD) buttons on the back Controls: Menu (Select), Down (Minus), Up (Plus), Source (Exit), Power Settings: Brightness, Contrast, Eco Mode, Clock, Phase, H. Position, V. Position, Image Ratio, Color Temperature, OSD H. Position, OSD V. Position, OSD Timeout, OSD Language, Input Select, Reset, Information, Auto adjust, Volume, Video Source (triggered by the hotkeys) Languages: English, French, Spanish, Simplified Chinese, Traditional Chinese, Korean, Russian, Portuguese. Japanese Lockouts: OSD, Power |
| Audio | Audio in Audio out |
| Speakers | Two x 2W internal speakers |
| Video | HDMI V1.4 Type A receptacle for HDMI input Analog VGA on Female DB-15 (DE-15) connector DisplayPort V1.2 - Supports later versions of Display Port video input Input Video Horizontal Sync frequency range: 30 – 82KHz Input Video Vertical Sync (frame rate) frequency range: 50 – 75Hz |
| Power | AC power input connector (IEC 60320 C6) AC input voltage range: 100-240VAC, 50/60Hz |
| Power Consumption (Typical) | ON (Default - 90% Brightness): 15W ON (Typical - 100% Brightness): 18.5W SLEEP (monitor + adapter): 0.5W OFF (monitor + adapter): 0.3W |
| Monitor Dimensions (without Stand) | 19.6" X 11.20" X 1.76" / 497.81 mm X 284.55 mm X 44.8 mm |
| Shipping Box Dimensions | 22.36" x 14.57" x 6.1" / 568 mm x 370 mm x 155 mm |
| Weight (Unpackaged) | 5.89 lbs / 2.67 kg |
| Weight (Packaged) | 11.02 lbs / 5 kg |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -20°C to 60°C / -4°F to 140°F |
| Humidity | Operating: 20% to 80%; Storage: 10% to 95% |
| MTBF | 50,000 hours demonstrated |
| Mounting Options | VESA 4-hole 100mm mounting interface on rear of unit |
| Warranty | 3-year |
| Regulatory approvals and declarations | Australia RCM Canada cUL, IC China CCC Europe CE, TUV United Kingdom UKCA Japan VCCI Korea KCC Taiwán BSMI United States UL, FCC International CB RoHS, China RoHS, WEEE |
| Compliance | GLI 10 kV air / 8 kV contact ESD compliant UL62368 ball-drop compliant IK06 impact compliant |
| What's in the Box | Touchmonitor HDMI cable Quick Install Guide EEI Label 4 x VESA screws NA Power Cord |
| Stands, Mounts & Kits | Wall Mount Kit (75mm or 100mm VESA) – Elo P/N: E143088 Tabletop Stand for 22'' I-Series (100mm VESA) - Elo P/N: E044356 Shelf Mount Bracket (75mm or 100mm VESA) - Elo P/N: E043382 Pole Mount Bracket (75mm or 100mm VESA) - Elo P/N: E045151 Elo Stand 1902/3-2202/3 - Black (100 mm VESA) - Elo P/N: E804330 Slim Self-Service Countertop Stand (75mm or 100mm VESA) - Elo P/N: E514693 Slim Self-Service Floor Stand (75mm or 100mm VESA) - Elo P/N: E514881 + E515260 |
