M-LUMA Pro A380 Octal
Standard height single slot PCIe Gen4 x16 eight-output graphics card with 12GB of memory
Drive eight 5Kp60 synchronized high-resolution displays or projectors from a single Matrox LUMA Pro Series graphics card. A single-slot PCIe® 4.0 x 16 card with eight native Mini DisplayPort™ 2.0 connectors, A380 Octal delivers extreme performance for multi-display video wall and digital signage applications.
For OEMs, system integrators, AV installers, and developers looking to create custom control functions, we also offer a complete range of video wall software, APIs, SDKs, and libraries. Matrox LUMA Pro Series is powered by Intel® Arc™ graphics.
With up to 12 GB of graphics memory, A380 Octal graphics card brings superior video playback and performance to a wide variety of video wall applications.
Drive multi-display 5K HDR video wall applications
LUMA Pro A380 Octal allows you to create powerful IP-based video walls with fewer components and smaller systems with the built-in MURA SDK media codec engine.
| Part number | LUMA-A380P8 |
|---|---|
| Bus type | PCIe 4.0 x 16 |
| Number of video outputs | 8 |
| Video output connectors | 8x Mini DisplayPort (secure) |
| DisplayPort specification | 2.0 UHBR10 |
| Maximum number of cards in a system | 2 |
| Performance | |
| Maximum resolution | 8x 5K60 HDR 12b |
| Bit depth and color space | Up to 36 bpp (Bits per Pixel) YCbCR 4:4:4 YCbCR 4:2:0 RGB |
| Memory | 12GB GDDR6 |
| GPU | 2x Intel® ArcTM A380E |
| Multi-stream audio | High-definition audio streams on four digital ports simultaneously |
| Additional features | |
| DisplayPort features | VESA DSC 1.1, and Adaptive Sync |
| HDCP compliance | 2.3 |
| Power connector | 6-pin PCIe |
| Board-to-board framelock | Max of 2 cards |
| Supported graphics API | DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3.0, Vulkan 1.3, oneAPI and OpenVINO |
| Hardware video encode/decode | H264/H265/AV1/VP9 |
| Hardware | |
| Form factor | Standard Height Single Slot |
| Dimensions | Length: 26.45 cm (10.41") Height: 12.68 cm (4.99") |
| Bracket | Standard Height |
| Environmental & Power consumption | |
| Cooling | Active |
| Power consumption | 130W |
| Operating temperature | 0 to 45 oC (32 to 113 °F) |
| Regulatory compliance | CE (EU) Class A, FCC (US) Class A, ICES-003 (Canada) Class A, KC (S. Korea) Class A, RCM (Aus/NZ) Class A, UKCA (UK) Class A, CSA/UL 62368-1, IEC 62368-1 |
| Environmental compliance | EU RoHS, China RoHS, REACH, WEEE |
| Software & API | |
| Matrox PowerDesk for Windows | Yes |
| Mura Developer tools | Yes |
| Operating systems | Windows 10 64-bit & LTSC (version 21H2 and up) / Windows 11 up to 24H2 and 64-bit LTSC (version 24H2) |
| System requirements3 | Single available PCIe 4.0 (or newer) x8 slot Intel Core Processor from 10th Gen to 14th Gen, Intel Xeon W-35xx/25xx/34xx/24xx processor for workstations Resizable BAR (reBAR) or Smart Access Memory (SAM) |
| Accessories (sold separately) | |
| Mini DisplayPort to DisplayPort adapter | CAB-MDP-DPF |
| Secure cable solution | SK-SLNB-4F |
