ID-EGPL-T102
Module Type: M.2 2280 to single 10GbE LAN Module, Function: LAN
- Marvell AQtion Ethernet Controller
- Support 10G/5G/2.5G/1000M/100M/10M LAN speed
- Lowest power and smallest 10GbE expansion solution
- Support x2/x1 PCI Express with Gen3/Gen2
- Tiny daughter board with high speed shielding cable
- Complies with EN61000-4-2 (ESD) Air-15kV, Contact-8kV
- Operation temperature 0°C to +55°C support
Datasheet
Product Specification
THE SMALLEST 10GBE M.2 LAN MODULE
EGPL-T102 condenses 10 GbE networking into an M.2 module, delivering speeds 10 times faster than Gigabit Ethernet while maintaining low power consumption and seamless integration with your existing network.
| Model Name | EGPL-T102 |
| Module Type | M.2 2280 to Single 10GbE LAN Module |
| Form Factor | M.2 2280 B+M Key |
| Function | LAN |
| Input I/F | PCI Express 3.0 x2 |
| Output I/F | 10GbE LAN |
| Output Port | 1 |
| Output Connector | RJ45 |
| Max. Power Consumption | 3.524W (3.3V, 1068mA) |
| Dimension (W x L x H/mm) | M.2 Board : 22 x 80 x 14.5 Daughter Board : 31.75 x 28 x 17.7 |
| Temperature | Operation : -20°C ~ 60°C (Ta) Storage : -55°C ~ 95°C (Ta) |
| Vibration | 5G@[7~2000Hz] |
| Shock | 50G@0.5ms |
| OS Support | Windows : 10 (64bit) and later releases Linux : Kernel 3.10 and later releases |
In today's data-driven world, organizations require high-speed, reliable network solutions to meet ever-growing bandwidth demands. Introducing the EGPL-T102 M.2 2280 10GbE LAN module - the industry's first M.2 10GbE expansion solution, engineered to transform your network infrastructure.
TINY, SPEEDY, EASY INTEGRATION
- 10x Speed Performance
10x current GbE speeds for faster, lower-latency data transmission - Excellent Compatibility
Supports 10/5/2.5/1Gbps and 100/10Mbps for excellent backward compatibility - Easy and Flexible Integration
RJ45 LAN port for 10GbE on existing Cat6/6A copper cables - Low Power Consumption
Increased efficiency through reduced power consumption, without sacrificing performance
Ordering Information
| P/N | Description |
| EGPL-T102-C1 | M.2 2280 to Single 10GbE LAN Module |
| EGPL-T102-C2 | M.2 2280 to Single 10GbE LAN Module, with PCIe Standard Bracket |
| EGPL-T102-C3 | M.2 2280 to Single 10GbE LAN Module, with Low-profile PCIe Bracket |
