AD-AIR-075

Edge AI Inference system powered by NVIDIA® Jetson Thor™

Anewtech-Systems-Embedded-PC-AI-Inference-System-AD-AIR-075
  • Powered by NVIDIA Jetson T5000™ and Jetson T4000™, delivering up to 2070 TFLOPS FP4 inference performance.
  • 19~36V wide power and -10~40 °C wide temp. supported.
  • Multiple I/O Expansion: 2x USB-C 3.2 Gen 2, 2x USB-A 3.2 Gen 1, 1x M.2 B Key (5G/LTE), and 2x M.2 E Key (NVMe / Wi-Fi).
  • Supports 4x 10GbE with RJ45 connectors.
  • Support WEDA / SUSI / Edge AI SDK / Inference Kit.
Datasheet
AD-AIR-075.pdf
Anewtech-Systems-Embedded-PC-AI-Inference-System-AD-AIR-075-AdvantechAnewtech-Systems-Embedded-PC-AI-Inference-System-AD-AIR-075-Advantech-Singapore
ModelAIR-075A-S6A1U
Processor
CPUNVIDIA Jetson T5000
AI Performance Reference2070 TFLOPS (FP4—Sparse)
Memory128GB 256-bit LPDDR5X , 273 GB/s
Storage
M.2M.2 B key (type 2242 & 2280)
I/O
COM Port2 COM (RS232/422/485)
USB2x USB 3.2 Gen1 Type C (USB 5 Gbps)
USB 3.22
CANBus2x DB9
AudioLine-Out, Mic-In
Display
HDMI1x HDMI 2.1, Max 3840 x 2160 (4K) at 60 Hz
DP1x DP 1.4a, Max 3840 x 2160 (4K) at 60 Hz
Ethernet
InterfaceRJ-45 optional PoE support (IEEE 802.3 af)
Speed4x 10GbE Ethernet (10M/100M/1G/2.5G/10Gbps)
Expansion
M.2 E-Key1 x M.2 2230 ( PCIe x1/USB2.0) for WIFI/BT
M.21 x M.2 3052 B Key (USB3.2 x1; USB2.0) for 5G
Rear I/O Interface
COM2 (1 x RS-232, 1 x RS-232/422/485)
I/O Interface
GPIO8 bit GPIO
Power
Power TypeAT / ATX
Power Supply Voltage19~36V DC input
Others
TPMTPM 2.0
Environment
Vibration3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis
Operating Temperature-15 ~ 40°C (non-POE) / -15 ~ 35°C (POE) with 0.7 m/s airflow (TDP 130W)
Relative Humidity40 °C @ 95%, Non-Condensing
Mechanical
Dimensions235.8 x 174 x 59 mm
Weight2.89Kg
MountingWall mounting kit
Operating System
UbuntuUbuntu 24.04 LTS with NVIDIA Jetpack™ 7.1
LinuxUbuntu 24.04.2
Software Support
Software APIAPI WEDA / SUSI / Edge AI SDK / Inference Kit compatible
Certifications
SafetyCB, UL, CCC, BSMI
EMCCE, FCC class B
