CT-BCO-1000-ADLN_2L
Semi-Rugged Fanless Mini Computer with Intel 12th® CPU, 1x DP, 2x COM, 2x LAN, 1x 2.5" Drive Bay
- Support 12th Gen Intel® IoTG Alder Lake-N Processor N97, QC, 12W
- DDR5 SODIMM. Max. up to 16GB (Default: 8GB)
- Dual Independent Display by 1x Display Port, 1x HDMI
- 2x Intel® I225-V 2.5GbE LAN
- 1x 2.5” Drive Bay
- 1x M.2 (B Key, (2242/ 2280/ 3042) (Default: 128GB M.2 SSD)
- 2x COM, 2x USB 3.2 Gen2, 2x USB 3.2 Gen1, 2x USB 2.0
- 9 to 36VDC Wide Range Power Input Supporting AT/ATX Mode
- Wide Operating Temperature 0°C to 50°C (12W CPU)
- TPM 2.0 Supported
- CE, FCC Class A
The powerful CPU performance positions it as an optimal choice for demanding industrial edge IoT applications, seamlessly providing cost-effective and deployment-ready solutions where reliability, speed, and integration are paramount.The BCO-1000-ADLN series, powered by the 12th Gen Intel® Core processor (Alder Lake-N97), strikes a balance between powerful performance and energy efficiency, making it ideal for industrial edge IoT applications. Its compact design, paired with the high-performance capabilities of the Alder Lake-N97 processor, ensures unmatched performance and reliability, catering to the diverse requirements of industrial environments.
With advanced features and a robust construction, this cutting-edge fanless mini computer seamlessly integrates into industrial setups, redefining the standards of industrial computing. Utilizing its advanced architecture, the BCO-1000-ADLN delivers faster performance, ensuring smoother operation, accelerated data processing, and overall enhanced efficiency.
| System | |
| Processor | Support 12th Gen Intel® IoTG Alder Lake-N Processor N97, QC, 12W |
| System Chipset | SoC integrated |
| LAN Chipset | 2x Intel® I225-V 2.5GbE LAN |
| Audio Codec | Realtek ALC897 |
| System Memory | DDR5 4800MT/s SODIMM. Max. up to 16 GB (Default: 8GB) |
| Graphics | Intel® UHD Graphics |
| BIOS | AMI UEFI BIOS |
| Watchdog | Software Programmable Supports 1~255 sec. System Reset |
| TPM | TPM 2.0 |
| Display | |
| Display Port | 1x DisplayPort 1.4a Max Resolution 4096 x 2304 @60Hz |
| HDMI | 1x HDMI 1.4b Max Resolution 3840 x 2160 @30Hz |
| Multiple Display | 2x Independent Displays |
| Storage | |
| M.2 B-Key | 1x M.2 B Key (2242/2280/3042, SATA/PCIe x1, support NVMe/SATA) |
| SATA | 1x Internal 2.5" SATA SSD Bay (7mm or 9mm) |
| Expansion | |
| M.2 E-Key | 1x M.2 E Key (2230, PCIe x1 & USB 2.0, support Wi-Fi & BT) |
| Operating System | |
| Windows | Windows 10/11 |
| Linux | Linux Kernel |
| I/O | |
| Audio | Line-in/Line-out/Mic-in |
| COM | 2x DB9 COM1: RS232/422/485 COM2: RS232 |
| DIO | 8x GPIO |
| LAN | 2x RJ45 (2.5GbE) |
| USB | 2x USB 3.2 Gen2 2x USB 3.2 Gen1 2x USB 2.0 Type-A |
| Others | 2x Antenna Holes 1x Power button 1x HD LED 1x Power LED |
| Power | |
| Power Adapter | Optional AC/DC 24V/9.2A, 60W |
| Power Mode | AT, ATX (Default ATX) |
| Power Supply Voltage | 9~36VDC |
| Power Connector | 3-pin Terminal Block |
| Environment | |
| Operating Temperature | 0°C to 50°C (12W CPU) Tested according to: IEC60068-2-1:2007 (Cold test procedure) IEC60068-2-2:2007 (Dry heat test procedure) IEC60068-2-3:2007 (Damp heat, steady state, test procedure) IEC60068-2-14:2009 (Wide temperature range thermal shock) |
| Storage Temperature | -30°C to 85°C |
| Relative Humidity | 10% to 95% (non-condensing) |
| Certification | EMC: CE FCC Class A (47 CFR part 15.109 and part 15.107) ICES-003 UKCA Green Product: RoHS 3.0 (Directive 2015/863/EU) REACH |
| Vibration | IEC60068-2-64:2008 With SSD: 5 Grms (5 - 500 Hz, 0.5 hr/axis) Designed to comply with MIL-STD-810G Method 514.7 Procedure I |
| Shock | IEC60068-2-27:2008 With SSD: 50G half-sin 11ms Designed to comply with MIL-STD-810G Method 514.7 Procedure I Package Drop Test: ISTA 2A |
| Physical | |
| Construction | 192 (W) x 140 (D) x 68 (H) mm |
| Weights | 1.5 kg |
| Construction | Extruded Aluminum with Heavy Duty Metal |
| Mounting Options | Wall Mounting DIN-Rail Mounting (Optional) |
