A-EPC-RPU
13th Gen Intel® Raptor Lake-P Fanless Compact System
- Intel® 13th Gen Raptor Lake-P Core™ Processor
- Intel® Iris® Xe / UHD Graphics for 13th Gen Intel® Processors
- One SO-DIMM Socket, Max. Up Max. up to 32GB DDR5 5200
- Triple Display, HDMI 2.0, DP 1.4 , USB Type C (Support DP)
- Dual Intel® 2.5 Gigabit Ethernet
- Triple Storage , 2.5" Drive Bay, M.2 Key B, Key-M (NVMe)
- Support TPM2.0, RAID 0/1, Wall Mount
- 12-24V DC Wide Range Power Input
Datasheet
Product Specification
| System Information | |
| Processor | Intel® Core™ i5-1335UE Processor (15W) Intel® Core™ i3-1315UE Processor (15W) |
| System Memory | 1 x 262-pin SO-DIMM socket Max. up to 32GB DDR5 4800MHz |
| I/O Chipset | EC iTE IT5782VG |
| BIOS Information | AMI BIOS, 256Mbit SPI Flash ROM |
| Watchdog Timer | H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step |
| H/W Status Monitor | System temperature monitoring and Voltages monitoring |
| RAID | RAID 0/1 (SATA) |
| TPM | Onboard TPM 2.0 IC |
| SBC | ECM-RPL |
| Expansion | |
| M.2 | 1 x M.2 Key-B 3042/3052/2242 (SATA3, USB3.0, w/SIM Card Slot) 1 x M.2 Key-M 2280(PCIe,Gen4x4) 1 x M.2 Key-E 2230(PCIe, USB2.0) |
| Storage | |
| M.2 | 1 x M.2 Key-B 2242 (SATA3) 1 x M.2 Key-M 2280 (NVMe, PCIe Gen4 x 4) |
| 2.5 Drive Bay | 1 x Internal 2.5 Drive Bay (7mm) |
| Front I/O | |
| USB | 2 x USB 2.0 |
| Power Button | 1 x Power Button |
| Reset Button | 1 x Reset button |
| COM Port | 2 x RS232/422/485 |
| LED Indicator | 1 x Power on/off LED 1 x Storage Access LED |
| Audio | 1 x Mic-in 1 x Line-out |
| Rear I/O | |
| USB | 3 x USB 3.2 Gen2 4 x USB 2.0 1 x USB Type C support DP/USB 3.2 Gen 1/PD 5V x 3A |
| LAN Port | 2 x RJ45 |
| DP | 1 x DP 2.1 |
| HDMI | 1 x HDMI 2.0b |
| Antenna | 2 x Antenna Mounting with Dust Protection Cover |
| AC/DC Input | 1 x Lockable DC Jack |
| Right I/O | |
| Antenna | 1 x Antenna Mounting with Dust Protection Cover |
| Left I/O | |
| Antenna | 1 x Antenna Mounting with Dust Protection Cover |
| Display | |
| Graphic Chipset | Intel® Iris®Xe/UHD Graphics for 13th Gen Intel® Processors |
| Resolution | 1 x DP 1.4 : Max. 7680 x 4320@60Hz 1 x HDMI 2.0b : Max. 4096 x 2160@60Hz 1 x DP 1.4 (from USB Type C): Max. 4096 x 2304@60Hz |
| Audio | |
| Audio Codec | Realtek ALC888S |
| Ethernet | |
| LAN Chipset | 2 x Intel® I226LM |
| Specification | 2 x 10/100/1000/2.5G Base-Tx GbE compatible |
| Power Requirement | |
| Voltage Input Spec. | Typical 12V/24V Power Input |
| Voltage Input Connector | Lockable DC Jack |
| ACPI | Single power ATX Support S0, S3, S4, S5 ACPI 5.0 Compliant |
| Power Mode | AT/ATX (ATX is default setting) |
| Adapter | Input: 100 ~ 240Vdc/ 50 ~ 60Hz Output: 12V/10A AC-DC 120W Adapter |
| Software Support | |
| OS | Win10, Win11, Linux |
| Certification | |
| Certification Information | CE, FCC, Class B, UKCA |
| Mechanical & Environmental | |
| Operating Temp. | With extended temperature peripherals: 0°C ~ 50°C (32°F ~ 122°F) with 0.5m/s air flow With 2.5” hard drive: 0°C ~ 40°C (32°F ~ 113°F) with 0.5m/s air flow |
| Storage Temp. | -30~70C° (-22°F ~ 158°F) |
| Operating Humidity | 40°C @ 95% Relative Humidity, Non-condensing |
| Dimension (W x L x H) | 177x 126 x 57mm (6.97” x 4.94” x 2.24") |
| Vibration Test | With SSD : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis |
| Shock Test | With SSD : 10 Grms, IEC 60068-2-27, Half Sine, 11ms |
| Drop Test | ISTA 2A, IEC-60068-2-32 Test : Ed, 1 Corner, 3 Edges, 6 Faces |
| Mounting Kit | Wall Mount Kit |
Ordering Information
| Ordering Information | 13th Gen Intel® Raptor Lake-P Core™ i5/i3 Fanless Compact System EPC-RPU-I5E-A1-1R (i5-1335UE) EPC-RPU-I3E-A1-1R (i3-1315UE) |
