A-HPM-621UA
Motherboard supports single 2nd Gen. Intel® Xeon® Scalable Processors / Intel® Xeon® Scalable Processors
- Intel FCLGA3647 Sockets supports 1st and 2nd Gen. Intel Xeon Scalable Processors (Max. TDP at 150W)
- Intel C621 Chipset
- 6 x DDR4 2933/ 2666/ 2400/ 2133 MHz RDIMM/ LRDIMM Up to 384GB
- TPM 2.0 onboard
- IPMI 2.0 with AST 2500 BMC controller onboard.
- 4 x Intel I210AT Giga-bit Ethernet
- 9 x SATA III Support RAID 0,1,5,10
- 2 x internal RS232 ports
Datasheet
Product Specification
| System Information | |
| Processor | Intel FCLGA3647 Sockets supports 1st and 2nd Gen. Intel Xeon Scalable Processors (Max. TDP at 150W) |
| Platform Controller Hub | Intel C621 Chipset |
| System Memory | 6 x DDR4 2933/ 2666/ 2400/ 2133 MHz RDIMM/ LRDIMM Up to 384GB |
| BIOS Information | AMI UEFI BIOS |
| Watchdog Timer | System Reset Event. 0 ~ 6553 seconds |
| H/W Status Monitor | CPU temperature, Fan speed and voltage monitoring, Fan speed control, and Case Open detection |
| TPM | TPM 2.0 onboard |
| iAMT | IPMI 2.0 with AST 2500 BMC controller onboard |
| Edge I/O (Rear) (CS) | |
| USB Port | 4 x USB 3.2 Gen1 ports |
| RJ-45 | 4 x RJ45 (LAN1 share IPMI port) |
| Display (CS) | |
| Graphic Chipset | AST 2500 BMC controller |
| Resolution | 1 x VGA port VGA: 1920 x 1200 @ 60Hz 32bpp |
| Expansion | |
| Expansion | 3 x PCIe x16 slots or 6 x PCIe x8 slots Slot 1, PCI 3.0 Slot 2, PCIe 3.0 x8 Slot 3, PCIe 3.0 x16 (x16 will switch to x8 automatically when Slot 2 is used) Slot 4, PCIe 3.0 x8 Slot 5, PCIe 3.0 x16 (x16 will switch to x8 automatically when Slot 4 is used) Slot 6, PCIe 3.0 x8 Slot 7, PCIe 3.0 x16 (Slot 7 is the slot closest to CPU, x16 will switch to x8 automatically when Slot 6 is used) |
| Storage | |
| M.2 | 1 x M.2 M-Key PCIe 3.0 x4 NVMe SSD, 2242/2260/2280 form factor |
| I/O | |
| USB Port | 2 x internal USB 2.0 Ports 2 x internal USB 3.2 Gen1 Ports |
| SATA | 9 x SATA III Support RAID 0,1,5,10 |
| Serial | 2 x internal RS232 ports |
| VGA | 1 x internal VGA port |
| CMOS Battery | 1 x Horizontal Socket Type CMOS Battery Holder with CR2450 |
| Ethernet | |
| LAN Chipset | 4 x Intel I210AT Giga-bit Ethernet |
| LAN Port | 4 x RJ45 (LAN1 Share IPMI Port) |
| Mechanical & Environmental | |
| Operating Temperature | 0 ~ 60°C (32 ~ 140°F) |
| Storage Temperature | -40 ~ 85°C |
| Operating Humidity | 40%~95% relative humidity, non-condensing |
| Weight | 0.97Kg |
| Power Connector | 1 x Std. 24 Pin ATX connector 1 x 8 Pin SSI 12V connector |
| Dimension (L x W) | 12" x 9.6" (304.8mm x 243.84mm), PCB thickness is 2.0mm. |
| Software Support | |
| OS Information | Windows 10 IOT Enterprise Windows Server 2016 Windows Server 2019 |
Ordering Information
| Part No. | Description |
| HPM-621UAA-A1R | ATX 1xLGA3647 Intel 1st/2nd Gen. C621 w/6xDDR4/3xPCIe x16/4x1GbE/6xUSB3.2/9xSATA3.0 |
