SSG-521E-E1CR24H

2U storage server. 24 hot-swap 3.5" SAS/SATA bays (SAS hardware RAID), PCIe 5.0

Single Socket E (LGA-4677) 5th/4th Gen Intel® Xeon® Scalable processors. Up to 300W TDP.
16 ECC DDR5-4800: LRDIMM/RDIMM
Two Dedicated PCIe 5.0 x16 AIOM slots (OCP 3.0 SFF compliant)
Up to 6x PCIe 5.0 Slots (Slot #2 populated by 3908 controller by default)
Server remote management: IPMI 2.0 / KVM over LAN / Media over LAN per node
24 3.5" Hot-swap SAS3/SATA3 drives, 2x Rear SATA Slots, 4x Optional Rear NVMe Slots, 2x NVMe/SATA M.2 (form factor: 2280)
4x 8cm hot-swap counter-rotate redundant PWM cooling fans
1600W Redundant Power Supplies Titanium Level (96%)
HW RAID support via Broadcom® 3908

Key Applications

Enterprise Server
iSCSI SAN
HPC, Data Center

Database Processing & Storage
Corporate Database
Appliance Optimized Storage Building Blocks

Datasheet

Storage Server SSG-521E-E1CR24H.pdf

Product Specification

Anewtech-Systems-Storage-Server-Supermicro-ASG-2015S-E1CR24H-superstorage Supermicro Servers Supermicro Singapore

Anewtech-Systems-Storage-Server-Supermicro-ASG-2015S-E1CR24H Supermicro Servers Supermicro Singapore

Anewtech-Systems-Storage-Servers-Supermicro-SSG-521E-E1CR24H-Data-center-Server

Supermicro Ready-to-Ship Gold Series Pre-Configured Server

Best-Selling Server Platforms, Pre-Configured with Key Components for Reduced Lead Times

Model: SSG-521E-E1CR24H-G1

CPU: 1x Intel® Xeon® 4510 (12Core/2.4GHz)
Memory: 4x 64GB DDR5-5600
M.2: 1x 960GB M.2 NVMe SSD
Storage: 2x 20TB 3.5” SATA
Networking: 1x Dual 10GbE RJ45
Power Supplies: 2x 1600W Titanium Level
Storage Controller: 1x SAS Controller - HW RAID via Broadcom® 3908

Anewtech-Systems-Supermicro-Gold-Series-GPU-Server-Data-Center-Server-AI-Server

Product SKUs	SuperServer SSG-521E-E1CR24H SuperServer SSG-521E-E1CR24H-G1 (Gold Series version with pre-configured components)
Motherboard	Super X13SEDW-F
Processor
CPU	Single processor(s) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
Note	Supports 120W - 300W TDP CPUs (Air Cooled)
System Memory
Memory	Slot Count: 16 DIMM slots Max Memory (2DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM
Memory Voltage	1.1 V
On-Board Devices
Chipset	Intel® C741
Network Connectivity	Via AIOM
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output
LAN	1 RJ45 Dedicated IPMI LAN port
USB	2 USB 3.0 port(s) (2 Rear_USB)
Video	1 VGA port(s)
Serial Port	1 COM Port(s) (1 rear)
DOM	2 Super DOM (Disk on Module) port
System BIOS
BIOS Type	AMI 32MB SPI Flash EEPROM
Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown
PC Health Monitoring
CPU	7 Phase-switching voltage regulator Monitors for CPU Cores, Chipset Voltages, Memory
FAN	Fans with tachometer monitoring Pulse Width Modulated (PWM) fan connectors Status monitor for speed control
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
Chassis
Form Factor	2U Rackmount
Model	CSE-826S3TS-R1K62P1
Dimensions and Weight
Height	3.5"
Width	17.2"
Depth	34"
Package	12" (H) x 29" (W) x 52" (D)
Weight	Net Weight: 52 lbs (23.59 kg) Gross Weight: 74.5 lbs (33.79 kg)
Available Color	Silver
Front Panel
Buttons	Power On/Off
LEDs	Network activity Power status SSD activity System information (overheat/UID)
Expansion Slots
PCI-Express (PCIe)	4 PCIe 5.0 x8 FH slot(s) 2 PCIe 5.0 x16 FH slot(s) 2 PCIe 5.0 x16 AIOM slot(s)
Note	PCIe slot 2 is occupied by the Storage Controller (default configuration). If NVMe Kit exists, PCIe Slot 3 is occupied by Storage Controller instead.
Drive Bays / Storage
Hot-swap	24x 3.5" hot-swap SATA3/SAS3 drive bays (2x 2.5" hot-swap SATA3 rear drive bays)
M.2	2 M.2 NVMe OR 2 M.2 SATA3 M-Key, 2280 and 22110
System Cooling
Fans	4 Heavy Duty 8cm Fan(s)
Power Supply	1600W Redundant Titanium Level power supplies
Dimension (W x H x L)	73.5 x 40 x 203 mm
AC Input	1000W: 100-127Vac / 50-60Hz 1600W: 200-240Vac / 50-60Hz
+12V	Max: 83.3A / Min: 0A (100Vac-127Vac) Max: 133A / Min: 0A (200Vac-240Vac)
12V SB	Max: 2.1A / Min: 0A
Output Type	Backplanes (gold finger)
Operating Environment
RoHS	RoHS Compliant
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (Non-Condensing) Non-operating Relative Humidity: 5% to 95% (Non-Condensing)

Large-Scale Storage Building Blocks

Cost-Effective Systems for Large-Scale Object Storage

As the amount of data produced by today’s AI, HPC and Cloud applications continues to increase, cost-effective scale-out storage is essential for any organization’s storage strategy.
Supermicro X13 designs maximize the efficiency and cost effectiveness of large-scale data storage with intelligent, highdensity, economically optimized designs.
