SYS-751GE-TNRT-NV1
DP liquid cooled AI development Server with 4x A100 PCIe GPUs
- Acoustically optimized for quiet operation
- Closed-loop liquid cooling for CPUs and GPUs
- 4 liquid-cooled NVIDIA A100 GPUs with NVIDIA® NVLink™ (2+2) installed
- Dual 4th Gen Intel® Xeon® Scalable Processors, 6444Y (16 cores at 3.6Ghz) installed
- Dual-port active-cooled NVIDIA Connect-X6 Dx 25G Network Adapter installed
- Supermicro Cloud Orchestrator AI software stack
- Ubuntu 22.04 LTS installed
Key Applications
- High Performance Computing
- AI Development
- AI/Deep Learning Training
Product Specification
| Product SKUs | SuperServer SYS-751GE-TNRT-NV1 |
| Motherboard | Super X13DEG-QT |
| Processor | |
| CPU | Dual Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors |
| Core Count | 16C/32T; 30MB Cache per CPU |
| Note | Supports up to 350W TDP CPUs (Air Cooled) Supports up to 350W TDP CPUs (Liquid Cooled) |
| GPU | |
| Max GPU Count | Up to 4 double-width GPU(s) |
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect |
| GPU-GPU Interconnect | NVIDIA® NVLink® Bridge (2+2) |
| System Memory | |
| Memory | Slot Count: 16 DIMM slots Max Memory (2DPC): 512GB 4800MT/s ECC DDR5 |
| Memory Voltage | 1.1V |
| On-Board Devices | |
| SATA | SATA (6Gbps) ; RAID 0/1/5/10 support |
| Chipset | Intel® C741 |
| Network Connectivity | 2 RJ45 10GbE with Intel® X550-AT2 1 RJ45 1GbE with ASPEED AST2600 1 SFP28 25GbE |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Input / Output | |
| LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s) 2 RJ45 10 GbE LAN port(s) 1 SFP28 25 GbE LAN port(s) |
| USB | 2 USB 3.2 Gen1 port(s) (front) 3 USB 3.2 Gen1 port(s) (rear) 1 USB 3.2 Gen2 port(s) (rear) |
| Video | 1 VGA port(s) |
| DOM | 2 SATA DOM (Disk on Module) port(s) |
| Audio | 7.1 HD Audio Line Out Mic in |
| System BIOS | |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Power configurations | Power-on mode for AC power recovery ACPI Power Management |
| Security | |
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| PC Health Monitoring | |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory 8+4 Phase-switching voltage regulator |
| FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis | |
| Form Factor | Tower or 5U Rackmount |
| Model | CSE-759TS-R2K21BP |
| Dimensions and Weight | |
| Height | 8.6" (218.4 mm) |
| Width | 17.9" (454.7 mm) |
| Depth | 27.6" (701 mm) |
| Package | 25.8" (H) x 15.3" (W) x 37.6" (D) |
| Weight | Gross Weight: 121 lbs (55 kg) Net Weight: 88 lbs (44 kg) |
| Available Color | Black Front & Black Body |
| Front Panel | |
| LED | HDD activity LED Information LED Network 1 activity LED Network 2 activity LED Power status LED |
| Buttons | Power On/Off button Reset button |
| Expansion Slots | |
| PCI-Express (PCIe) Configuration | Default 7 PCIe 5.0 x16 FHFL slot(s) |
| Drive Bays / Storage | |
| Drive Bays Configuration | Default: Total 8 bay(s) 8 front hot-swap 2.5" NVMe/SAS*/SATA drive bay(s) (*SAS support may require additional storage controller and/or cables) |
| M.2 | 2 M.2 NVMe slot(s) (M-key) |
| System Cooling | |
| Fans | 1 fan 8cm Fan(s) 2 fan 12cm Fan(s) |
| Liquid Cooling | Direct to Chip (D2C) Cold Plate (optional) |
| Power Supply | 2200W Redundant Titanium Level power supplies |
| Dimension (WxHxL) | 106.5 x 82.1 x 203.5 mm |
| +12V | Max: 100A / Min: 0A (100Vac-127Vac) Max: 150A / Min: 0A (200Vac-220Vac) Max: 165A / Min: 0A (220Vac-230Vac) Max: 183.33A / Min: 0A (220Vac-240Vac) (for UL/cUL only) Max: 174.17A / Min: 0A (230Vac-240Vac) |
| 12V SB | Max: 3A / Min: 0A |
| AC Input | 1200W: 100-127Vac / 50-60Hz 1800W: 200-220Vac / 50-60Hz 1980W: 220-230Vac / 50-60Hz 2200W: 220-240Vac / 50-60Hz (For UL/cUL Only) 2090W: 230-240Vac / 50-60Hz 2090W: 230-240Vdc / 50-60Hz (for CQC only) |
| Output Type | Backplanes (gold finger) |
| Operating Environment | |
| Environmental Spec. | Operating Temperature: 10°C ~ 25°C (50°F ~ 77°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
Liquid Cooled AI Development Platform,
Plug-and-Play for Advanced AI Developers
Ridiculously Powerful, NVIDIA AI Enterprise Software Ready, Whisper Quiet
- CPU: Liquid-cooled Dual 4th Generation Intel® Xeon® Scalable 6444Y Processors
- GPU: Liquid-cooled 4 NVIDIA A100 PCIe 80GB with NVLink™ Bridge (2 + 2)
- Memory: 16 DIMM Slots with 512GB DDR5 4800MHz
- Drives: 6 1.9TB drives with total of 11.4TB of storage
- Networking: NVIDIA ConnectX®-6 Dx 25G
Watch our short video to learn more!
