A-CAXA0
10.1" Semi-Rugged Tablet with Intel® Celeron® Processor N3350 / N4200
- Intel® Celeron® Processor N3350/N4200
- MIL-STD-810G & IP65 certified, 4-feet drop resistance
- 10.1” TFT color LCD 1280 x 800 HD
- Corning Gorilla Glass, 10 point projected capacitive multi-touch panel
- High mobility with multiple connectivity including WLAN, Bluetooth, NFC
- Light Design, Weight only 1Kg with Battery
- G-sensor, light sensor, 2M/8M Camera
- Option SCR, 1D/2D Barcode scanner
Datasheet
| System Information | |
| Processor | Intel® Celeron® Processor N3350/N4200 |
| System Memory | Onboard LPDDR4 4GB / 8GB |
| Storage | |
| Solid State Drive | M.2 128GB solid state drive |
| Power Requirement | |
| Battery | 28.44W Li-ion battery |
| Battery Operating Time | 6 Hours |
| DC Input Connector | DC Jack |
| DC Input | +19V |
| Software Support | |
| OS | Windows 10 IoT 64bit Android 8.1 without NFC Android 11 without NFC |
| In-Box Accessory | |
| Accessory | +19V 65W power adaptor |
| Panel | |
| LCD Size | 10.1" |
| Display Type | WXGA |
| Resolution | 1280 x 800 |
| Luminance | 300 cd/m2 |
| Touch Type | 10 points projective capacitive |
| I/O | |
| HDMI | 1 x HDMI output |
| USB Port | 2 x USB 3.0 Type A |
| Other | 1 x Audio Jack 1 x Micro SD 1 x DC Jack |
| System Control | |
| Control Buttons | 1 x Power button 1 x Barcode scanner trigger |
| LED Indicator | 1 x Power |
| Data Collection | |
| Barcode Scanner | 1D/2D Barcode scanner (optional) |
| NFC | ISO/IEC 14443 A/B, 15693/18092, NFCIP-1, NFCIP-2, support MIFARE and Felica |
| Camera | 2MP Front camera 8MP Rear camera with auto focus |
| Wireless Communication | |
| Bluetooth | Bluetooth 5.0 |
| WLAN | 802.11 a/b/g/n/ac |
| Mechanical & Environmental | |
| Operating Temp. | 0°C ~ 40°C (32°F ~104°F) 0°C ~ 30°C (32°F ~ 86°F) without dock or wall mount [EN60601] 0°C ~ 40°C (32°F ~104°F) with dock or wall mount [EN60601] |
| Storage Temp. | -20°C ~ 60°C (-4°F ~ 140°F) |
| Operating Humidity | 40°C @ 95% relative humidity, non-condensing |
| Weight | 1 kg with Battery |
| Vibration Test | MIL-STD-810G method 514.6 procedure 1 |
| Shock Test | MIL-STD-810G method 516.6 procedure 1 |
| Drop Test | 4-Feet drop on concrete floor, MIL-STD-810G 516.6 procedure IV |
| IP Rating | IP65 |
| Dimension (W x L x H) | 281 x 193.3 x 19.95mm |
| Fanless | Fanless |
| Construction | Rubber + plastic |
| Component | |
| Adapter | Input: 100~240Vac/50~60 Hz Output: 65W adaptor (19V@3.15A adaptor) |
| Microphone | Front microphone |
| Packing List | |
| Packing List | 1 x CAXA0 1 x Power adapter 1 x Battery |
